| Basic parameters |
Model |
RE-52AA |
| |
Glass Material |
GG-17 |
| |
Bracket Material |
Spraying anticorrosion |
| |
Material of pot shell |
Spraying anticorrosion 250*365*150mm |
| |
Material of Pan gallbladder |
Stainless steel 240*120mm |
| |
Rotating bottle volume |
1L 24#Standard mouth |
| |
Collect bottle volume |
0.5L 24#Standard mouth |
| |
vacuum degree |
0.098Mpa |
| |
Rotating power |
30W |
| |
Rotating speed |
0-120rpm |
| |
heating power |
1KW |
| |
Temperature control range of bathtub |
0-99℃ |
| |
Rotating bottle volume |
±1℃ |
| |
Lifting power |
15W1/15 |
| |
Lifting trip |
120mm |
| |
Voltage/frequency(V/Hz) |
220V/50Hz |
| |
Shape size(mm) |
700*440*1005 |
| |
Packing dimensions(mm) |
590*460*460 0.12square |
| |
Packing weight (KG) |
21 |
| Function Configuration |
Speed regulation mode |
e-cvt |
| |
Temperature display mode |
CU50Type 1 sensordigital display |
| |
temperature control |
Intelligent Temperature Control |
| |
Sealing method |
Tetrafluoro Component Sealing |
| |
condenser |
Vertical condenser85*460mm 29#Standard mouth |
| |
Lifting mode |
Host automatic lifting |
| |
Continuous Feeds |
19#Label feeding valve |
